  9. FloatSwitch, 20ft, Polypropylene, 125VAC
No Product Image Available

FloatSwitch, 20ft, Polypropylene, 125VAC

  • Mfr # 20MAPWCWNOEZ

  • Zoro # G215822432

product price: $71.49
/ea

Key Features

Float Material
Polypropylene
Float Length
4 7/8 in
Switch Type
Tether Float
Series
EZconnex
Contact Form
Normally Open
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
20MAPWCWNOEZ
Zoro #
G215822432
UPC #
-
Country of Origin
United States

Dimensions

Float Length
4 7/8 in
Manufacturers Warranty Length
5 yr
Tether Length - Minimum
3 1/2 in
Cord Length
20 ft
Float Diameter
2 3/4 in
Tether Length - Maximum
22 in

Details

Float Material
Polypropylene
Switch Type
Tether Float
Series
EZconnex
Contact Form
Normally Open
Mounting Bracket Material
Stainless Steel
Item
Float Switch
Standards
CSA, UL Listed
Includes
Mounting Bracket
Actuation Method
Mechanically-Activated
Off Point
45 Degrees Below Horizontal
NEC Cord Designation
SJOW
Electric Load Current - Minimum
1 mA @ 125V AC, 1 mA @ 30V DC, 1 mA @ 4V DC
Number of Floats
1
Starting Current - Maximum
1 A
Liquid Temperature - Maximum
140 Degrees F
Electrical Connection
2-Conductor Wire Leads
Electric Load Current - Maximum
0.1 A @ 30V DC, 1 A @ 125V AC
On Point
45 Degrees Above Horizontal
Compatible Manufacturer Part Number
20MAPWCWNOEZ
Rated Voltage
125V AC
Mounting Hardware Included
Mounting Bracket
Counterweight Type
No Counterweight
Switch Duty
Control Duty
Compatible Pump Type
Sewage Pump
Running Current - Maximum
1 A

Description

Float Switch

Restrictions

This is a restricted item in the USA. It cannot be used for potable water applications.
