Air Gripper, 180 degree Angular Style
Mfr # MHY2-25D
Zoro # G615377839
product price:Â
$
368.99
/ea
Free Shipping & Returns
Key Features
Open Width
135 mm
Maximum Operating Pressure
87 psi
Series
MHY2
Seal Material
Rubber
Finger Material
Stainless Steel
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- MHY2-25D
- Zoro #
- G615377839
- UPC #
- -
- Country of Origin
- Japan
Dimensions
- Open Width
- 135 mm
- Inlet Size
- M5
- Overall Length
- 107 mm
- Overall Width
- 58 mm
- Overall Height
- 30 mm
- Bore Diameter
- 25 mm
- Wire Rope Length
- 107 mm
- Length
- 107 mm
Details
- Item
- Air Gripper
- Maximum Operating Pressure
- 87 psi
- Series
- MHY2
- Seal Material
- Rubber
- Finger Material
- Stainless Steel
- Air Inlet Type
- Metric
- Gripper Rotation
- 180 Degrees
- Standards
- RoHS Compliant
- Maximum Operating Temperature
- 140 Degrees F
- Minimum Operating Pressure
- 15 psi
- Repeatability
- +/-0.2 mm
- Weight
- 560 g
- System of Measurement
- Metric
- Minimum Operating Temperature
- 14 Degrees F
Description
Air Gripper, Series MHY2, Open Width 135 mm, Maximum Operating Pressure 87 psi, Minimum Operating Pressure 15 psi, Overall Length 107 mm, Overall Width 58 mm, Overall Height 30 mm, Finger Material Stainless Steel, Maximum Operating Temperature 140 Degrees F, Gripper Rotation 180 Degrees , Minimum Operating Temperature 14 Degrees F, Standards RoHS Compliant, Inlet Size M5, Air Inlet Type Metric, Weight 560 g, System of Measurement Metric, Seal Material Rubber
