CYLINDER, COMPACT

  • Mfr # CDQSB16-100DC

  • Zoro # G513344865

product price:
$
63.99
/ea

Key Features

Cylinder Action
Double Acting
Body Material
Aluminum
Cylinder Type
Compact
Magnetic Piston
Magnetic Piston
Piston Material
Aluminum
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
CDQSB16-100DC
Zoro #
G513344865
UPC #
-
Country of Origin
Japan
Cylinder Action
Double Acting
Item
Compact Cylinder
Body Material
Aluminum
Cylinder Type
Compact
Magnetic Piston
Magnetic Piston
Piston Material
Aluminum
Piston Rod Material
Stainless Steel
Standards
RoHS Compliant
Cushion Type
Rubber Cushion
Lead Wire Type
No Lead Wire
Minimum Operating Pressure
10.15 MPa
Rod Gender
Female
Air Inlet Center to Center Distance
104.5 mm
For Fluid Type
Air
Rod Rotation
Rotating Rod
Weight
0.06 kg
Body Material Finish
Anodized
Maximum Operating Pressure
145 MPa
Minimum Operating Temperature
14 Degrees F
Number of Rods
Single Rod
Actuation Type
Air Extend, Air Retract
Series
CQS
Mounting Orientation
Horizontal, Vertical
System of Measurement
Metric
Cylinder Repair
Non-Repairable
Maximum Operating Temperature
158 Degrees F
Air Inlet Type
Metric Standard
Inlet Gender
Female
Piston Rod Material Grade
304

Description

Compact Cylinder, Body Material Aluminum, Cylinder Type Compact, Cylinder Repair Non-Repairable, Magnetic Piston Magnetic Piston, Mounting Type Tapped Hole, Through Hole, Bore Diameter 16 mm, Cushion Type Rubber Cushion, Stroke Length 100 mm, Inlet Size M5 x 0.8, Air Inlet Type Metric Standard, Spring Retraction Force Not Applicable, Cylinder Action Double Acting, Number of Rods Single Rod, System of Measurement Metric, Body Material Finish Anodized, Mounting Location Front, Rear
