Shop SMC

Solenoid Air Control Valve, 113 mm L

  • Mfr # VP342-3DZ1-02NA

  • Zoro # G621914776


product price:
$
78.29
/ea

Key Features

Body Features
Single
Number of Ports
3
Product Type
Solenoid Air Control Valve
Coefficient of Volume (Cv)
1
Voltage
110V AC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
VP342-3DZ1-02NA
Zoro #
G621914776
UPC #
-
Country of Origin
Japan

Dimensions

Overall Width
27 mm
Inlet Port Connection Size
1/4
Exhaust Port Connection Size
1/4
Overall Height
83 mm
Wire Rope Length
113 mm
Overall Length
113 mm
Length
113 mm

Details

Body Features
Single
Number of Ports
3
Product Type
Solenoid Air Control Valve
Coefficient of Volume (Cv)
1
Voltage
110V AC
Operating Pressure - Maximum
0.7 MPa
Body Material
Aluminum
Operating Temperature - Minimum
-10 Degrees C
Body Style
Body-Ported
Response Time
38 msec
Seal Material
Rubber
Power Consumption
0.55 W
Valve Action
Normally Closed
Includes Solenoid Coil
Solenoid Coil Included
Actuator Type
Single Solenoid
Number of Positions
Two-Position
Series
VP300
Inlet Port Connection Gender
Female
Exhaust Port Connection Gender
Female
Exhaust Port Connection Type
NPT
Electrical Connection Type
DIN Solenoid Connector
Operating Pressure - Minimum
0.2 MPa
Inlet Port Connection Type
NPT
Operating Temperature - Maximum
50 Degrees C
Item
Solenoid Air Control Valve
Override
Non-Locking
Valve Type
Spool
Pilot Port Connection Gender
Female
Pilot Pressure
0.2 MPa
Return Action
Spring Return
Number of Ways
Three-Way

Description

Solenoid Air Control Valve, Voltage 110V AC, Center Position Not Applicable, Body Style Body-Ported, Pilot Pressure 0.2 MPa, Power Consumption 0.55 W, Override Non-Locking, Overall Height 83 mm, Overall Length 113 mm, Overall Width 27 mm
