  11. THHN; THWN Building Wire, Copper, 14 AWG, 1C, Red, Stranded, 50 ft
Southwire THHN; THWN Building Wire, Copper, 14 AWG, 1C, Red, Stranded, 50 ft 22957583 - main

THHN; THWN Building Wire, Copper, 14 AWG, 1C, Red, Stranded, 50 ft

  • Mfr # 22957583

  • Zoro # G607946579

product price: $24.39
/ea
Sold in multiples of 2 for $48.78

Key Features

Trade Designation
THHN; THWN
Wire Size
14 AWG
Conductor Material
Copper
Number of Conductors
1C
Jacket Color
Red
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
22957583
Zoro #
G607946579
UPC #
32886918377
Country of Origin
United States

Dimensions

Wire Size
14 AWG
Length
50 ft
Nominal Outside Dia.
0.113 in
Insulation Thickness (Mils)
15mils
Jacket Thickness (Mils)
5mils

Details

Item
Building Wire
Trade Designation
THHN; THWN
Conductor Material
Copper
Number of Conductors
1C
Wire Color
Red
Jacket Color
Red
Jacket Material
Nylon
Conductor Design
Stranded
Insulation Material
Thermoplastic
Voltage
600V AC
Temp. Rating
90°C
Standards
ASTM - B3; UL Standards 83 and 758; CSA C22.2 No. 75; NOM-ANCE; Federal Specification A-A-59544; National Electrical Code, NFPA 70; VW-1; FT1; RoHS/REACH Compliant
Max. Amps
15
Stranding
19
Applications
ApplicationTHHN copper conductors are primarily used in conduit and cable trays for services, feeders and branch circuits in commercial or industrial applications as specified in the National Electrical Code. Voltage for all applications is 600 volts.THWN- Wet locations not to exceed 75° C or dry locations not to exceed 90° C or locations not to exceed 75° C when exposed to oil.
Allowable Ampacity At 75C
15
Construction
ConstructionSouthwire® THHN copper conductors are made with soft drawn copper. Combination-unilay stranding. The wire is covered with a tough heat and moisture resistant PVC insulation with an overall nylon jacket. Marked as THWN.

Description

50', 14 Stranded, Red Building Wire, Type THHN, Nylon Jacketed, 90 Degrees Celsius, Copper, 600V, Plastic Spool

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
