  9. Air Angle Grinder, Light, 0.5 HP, 90 psi
Shop All Air Drills
Speedaire

Air Angle Grinder, Light, 0.5 HP, 90 psi

product price: $121.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • HP 0.5
  • HP - Air Tools 0.50
  • Chuck Size - Air Drills 1/2 in
  • CFM @ Full Load 23.8
  • Air Inlet 1/4 in NPT
See all product information

Product Information

  • Brand Speedaire
  • MFR # 48MA03
  • Zoro # G5234227
  • UPC #
    190735986400
  • Country of Origin Taiwan, Province of China
  • Category Air Drills

Dimensions

Chuck Size - Air Drills 1/2 in
Min. Hose Size 3/8 in
Overall Length 9 in
Chuck Size 1/2 in
Air Inlet Size - Air Tools 1/4 in NPT
Right Angle Length 6 7/8 in
Overall Width 1 3/4 in
Spindle Screw Size M5
Overall Height 6 5/8 in
Spindle Thread Size 3/8"-24

Details

Item Drill
HP 0.5
HP - Air Tools 0.50
CFM @ Full Load 23.8
Air Inlet 1/4 in NPT
Drill Chuck Type - Air Drills Keyed
Reversing Yes
Required Pressure 90 PSI
Free Speed 500 RPM
Duty Cycle - Air Tools Light Duty
Torque 1.10 ft-lb
Body Style - Air Tools Pistol
Gear Train Planetary
Tool Weight 3.5 lb
Variable Speed No
Item - Air Drills Air Drill
Average CFM @ 15 Second Run Time 6.00
Includes Chuck Key, Side Handle
Bearings Ball
Duty Light
Handle Material Aluminum
Style Pistol
Throttle Type Trigger
Drill Chuck Type Keyed
Housing Material Aluminum
Handle Type Pistol Grip
Drilling Capacity in Aluminum 1/2 in
Drilling Capacity in Cast Iron 1/2 in
Torque Range 1.1 ft-lb to 10 ft-lb
Drilling Capacity in Wood 1/2 in
Air Pressure 90 psi
Exhaust Location Handle
Power Source Air-Powered
Reversible Yes
Bearing Design Ball
Min. Torque 1.1 ft-lb
Max. Torque 10 ft-lb
Noise Level 85 dB
Drilling Capacity in Steel 1/2 in
Vibration Level 2.5 m/sq sec
Horsepower 0.5 hp
Duty Rating Light Duty
Air Consumption 6 cfm

Description

Drill, Reversing Yes, Pistol Body Style - Air Tools, Free Speed 500 RPM, Torque 1.10 ft-lb, Average CFM @ 15 Second Run Time 6.00, CFM @ Full Load 23.8, Required Pressure 90 psi, Min. Hose Size 3/8 in, Handle Material Aluminum, Variable Speed No, Throttle Type Trigger, Bearings Ball, Housing Material Aluminum, Gear Train Planetary, Overall Length 9 in, Right Angle Length 6 7/8 in, Tool Weight 3.5 lb
