Speedaire Desiccant Dryer, 4 Stage, 15 CFM 4UDK5 - main

Desiccant Dryer, 4 Stage, 15 CFM

  • Mfr # 4UDK5

  • Zoro # G8532955

product price: $511.99
/ea
Free Shipping & Returns

Key Features

Includes
(1) Qt Desiccant
Overall Height
11 1/4 in
Drain Type
Manual
Filter Rating
0.01 micron, 5 micron, 40 micron, 70 micron
Connection Size - Air Treatment
1/2 in NPT
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
4UDK5
Zoro #
G8532955
UPC #
190735629963
Country of Origin
United States

Dimensions

Overall Height
11 1/4 in
Connection Size - Air Treatment
1/2 in NPT
Overall Width
14 1/4 in
Height (In.)
11 1/4 in
Width (In.)
14 1/4 in
Bowl Size - Air Treatment
6.0 oz, 32.0 oz
Length (In.)
11 1/4 in
Overall Length
11 1/4 in
Air Outlet Size
1/2 in
Air Inlet Size
1/2 in

Details

Item
Desiccant Air Dryer
Includes
(1) Qt Desiccant
Drain Type
Manual
Filter Rating
0.01 micron, 5 micron, 40 micron, 70 micron
Application
Air Gauging Equipment, Lab Air, Paint Spray
Total Capacity (Cu.-Ft.)
2,500
Max. Flow - Air Treatment
15 cfm
Max. SCFM @ 100 PSI
15
Desiccant Material
Silica Gel
Element Material
Sintered Bronze/paper pleaded
Microns
5 and .01
CFM
15
ISO Class
2
Max. Incoming Pressure - Air Treatment
125 psi
Adjustment Range - Air Treatment
5 to 125 psi
Max. Operating PSI
125
(M)NPT Outlet (In.)
1/2
Max. Operating Temp. (F)
120 Degrees F
For Removal Of
Debris, Dirt, Oil, Oil Vapors, Pipe Scale, Rust, Water, Water Vapors
Type
4-Stage
Bowl
Metal
Total Capacity - Air Treatment
2,500 cu ft
Dew Point - Air Treatment
-30 Degrees F
Dew Point (Deg. F)
-30
Item - Multi Stage Air Dryers
4 Stage Desiccant Dryer
Bowl Material - Air Treatment
Metal
Filter Rating - Air Treatment
0.01 micron, 5 micron
Inlet/Outlet NPTF (In.)
1/2
(F)NPT Inlet (In.)
1/2
Bowl Material
Metal
Body Material
Metal
Series
Standard
Total Air Capacity
2,500 cu ft
Filter Element Compatibility
EK35-5, EK55A
Number of Air Outlets
1
Stage 2 Filter Type
5 micron Sintered Bronze Filter and Regulator
Maximum Flow Rate
15 cfm
Air Inlet Type
NPT
Filter Type
Coalescing, Particulate
Stage 1 Filter Type
5 micron Sintered Bronze Filter and Regulator
Stage 3 Filter Type
0.01 micron Coalescing Filter
Filtered Substance
Dust, Water Vapor
Maximum Operating Pressure
125 psi
Bowl Capacity
6 oz, 32 oz
Stage 4 Filter Type
Desiccant Dryer
Weight
10 lb
Filter Included
Yes
Air Outlet Type
NPT
Number of Stages
4
Filter Element Material
Sintered Bronze
Number of Air Inlets
1
Standards
ISO
Maximum Operating Temperature
120 Degrees F
Dew Point
-40 Degrees F

Description

Desiccant Air Dryer, ISO Class 2, Air Inlet Size 1/2 in, Air Inlet Type NPT, Maximum Flow Rate 15 cfm, Overall Length 11 1/4 in, Overall Width 14 1/4 in, Maximum Operating Pressure 125 psi, Dew Point -40 Degrees F, Filter Rating 0.01 micron, 5 micron, 40 micron, 70 micron, Filter Included Yes, Number of Stages 4, Air Outlet Size 1/2 in, Air Outlet Type NPT, Application Air Gauging Equipment, Lab Air, Paint Spray, Body Material Metal, Bowl Capacity 6 oz, 32 oz, Bowl Material Metal
