  13. 208VAC Non-Reversing Magnetic Contactor 3P 9A NEMA 00

This item is Discontinued.

Square D 208VAC Non-Reversing Magnetic Contactor 3P 9A NEMA 00 8502SAO12V08

208VAC Non-Reversing Magnetic Contactor 3P 9A NEMA 00 (Discontinued)

  • Mfr # 8502SAO12V08
  • Zoro # G2403274
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
8502SAO12V08
Zoro #
G2403274
UPC #
785901340683
Country of Origin
Mexico

Dimensions

NEMA Contactor Size
00
Height
4.34 in
Width
3.22 in
Depth
4.22 in
NEMA Size
0
Overall Depth
4.22 in
Overall Height
4.34 in
Overall Width
3.22 in

Details

Item
Magnetic Contactor
Full Load Amps
9 A
Action
Non-Reversing
Number of Poles
3
Coil Volts
208V AC
Reversing
No
HP @ 3 Phase - 208V
1 1/2 hp
HP @ 3 Phase - 575V
2 hp
HP @ 3 Phase - 240V
1 1/2 hp
HP @ 3 Phase - 480V
2 hp
Enclosure NEMA Rating
No Enclosure
Hz
50/60
Frame / Series / Class / Code
Class 8502
Standards
CSA, UL Listed
Auxiliary Contact Form
Auxiliary Contacts Not Included
Terminal Connection Type
Screw Clamp Terminals
Contactor Style
NEMA
Number of Auxillary Contacts
0
Includes Auxiliary Contacts
No
NEMA Enclosure Rating
No Enclosure
Coil Voltage
208V AC
Maximum Voltage Rating
600V AC
Frequency
60 Hz
Full Load Current - Inductive
9 A
Horsepower @ Three Phase - 600V AC
2 hp
Horsepower @ Three Phase - 240V AC
1 1/2 hp
Reversing Capability
Non-Reversing
Horsepower @ Single Phase - 240V AC
1 1/2 hp
Phase
Three
Horsepower @ Three Phase - 480V AC
2 hp
Horsepower @ Three Phase - 208V AC
1 1/2 hp

Description

NEMA Magnetic Contactor, Auxiliary Contact Form Auxiliary Contacts Not Included, NEMA Enclosure Rating No Enclosure, NEMA Size 0, Coil Voltage 208V AC, Number of Poles 3, Full Load Current - Inductive 9 A, Reversing Capability Non-Reversing, Overall Height 4.34 in, Overall Width 3.22 in, Terminal Connection Type Screw Clamp Terminals, Number of Auxillary Contacts 0, Contactor Style NEMA, Horsepower @ Three Phase - 240V AC 1 1/2 hp, Horsepower @ Three Phase - 480V AC 2 hp, Phase Three
