Shop SQUARE D
See all product information
Create Account
Circuit Breakers & Accessories
Mfr # HOMT225230
Zoro # G223549994
product price:Â
$
149.99
/ea
Free Shipping & Returns
Zoro's best price: not eligible for any other offers or promotions
Key Features
Depth
3.2 in
Frame Size
30A/HOM
Compatible Panelboard/Load Center Series
HOM
Circuit Breaker Type
Quad Tandem
Min. Wire Size
14 AWG
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- HOMT225230
- Zoro #
- G223549994
- UPC #
- 785901970385
- Country of Origin
- Mexico
Dimensions
- Depth
- 3.2 in
- Frame Size
- 30A/HOM
- Min. Wire Size
- 14 AWG
- Width
- 2 in
- Max. Wire Size
- 8 AWG
- Length
- 3.1 in
Details
- Item
- Circuit Breakers & Accessories
- Compatible Panelboard/Load Center Series
- HOM
- Circuit Breaker Type
- Quad Tandem
- For Use With
- Homeline Load Centers
- Amps
- 25 A, 30 A
- Terminal Connection
- Plug-In
- Circuit Breaker Mounting Style
- Plug In
- AC Voltage Rating
- 120/240V AC
- Standards
- UL Listed
- Max. AIR Rating
- 10kA at 120/240V AC
- Number of Poles
- 2
- Max. Operating Temp.
- 104 Degrees F
Description
Circuit Breakers & Accessories, Amps 25 A, 30 A, AC Voltage Rating 120/240V AC, Circuit Breaker Type Quad Tandem, Number of Poles 2, Circuit Breaker Mounting Style Plug In, Compatible Panelboard/Load Center Series HOM, Max. AIR Rating 10kA at 120/240V AC, For Use With Homeline Load Centers, Terminal Connection Plug-In, Frame Size 30A/HOM, Length 3.1 in, Width 2 in, Depth 3.2 in, Max. Operating Temp. 104 Degrees F, Min. Wire Size 14 AWG, Max. Wire Size 8 AWG, Standards UL Listed
Restrictions
WARNING:
Cancer and Reproductive Harm
For more information go to
www.P65Warnings.ca.gov
