  15. Illuminated push-button head, Harmony 9001K, metal, plastic guard flush, green, 30mm, spring return, LED green, 24-28V
Square D Illuminated push-button head, Harmony 9001K, metal, plastic guard flush, green, 30mm, spring return, LED green, 24-28V 9001K1L35LGG - main

Illuminated push-button head, Harmony 9001K, metal, plastic guard flush, green, 30mm, spring return, LED green, 24-28V

  • Mfr # 9001K1L35LGG

  • Zoro # G3302123

product price: $160.99
/ea
Free Shipping & Returns

Key Features

Push Button Style
Flush
Operator Illumination
Illuminated
Panel Cutout Diameter
30 mm
Head Color
Green
Head Material
Plastic
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9001K1L35LGG
Zoro #
G3302123
UPC #
-
Country of Origin
Mexico

Dimensions

Panel Cutout Diameter
30 mm
Mounting Diameter
30 mm

Details

Item
Push Button Operator
Push Button Style
Flush
Operator Illumination
Illuminated
Head Color
Green
Head Material
Plastic
Standards
EN/IEC 60947-5-4 || EN/IEC 60947-5-1 || CSA C22.2 No 14 || EN/IEC 60947-1 || UL 508 || JIS C 4520 || JIS C 852
Bezel Material
metal
Operator Profile
red flush, unmarked, flush
Shock Resistance
50 gn IEC 60068-2-27
Light Source Colour
green
Light Source
Green LED
Shape Of Signaling Unit Head
round
Product Or Component Type
head for illuminated push-button
Ip Degree Of Protection
IP66 IEC 60529
Operating Position
any position
Operator Additional Information
plastic guard
Bulb Base
BA 9s
Contacts Type And Composition
without contact block
Protective Treatment
TC
[Us] Rated Supply Voltage
24 to 28 V
Product Certifications
UL 508 || NEMA
Cap/Operator Or Lens Colour
green
Ambient Air Temperature For Storage
-40-70°C
Mechanical Durability
5000000 cycles
Vibration Resistance
7 gn 2-500 Hz)IEC 60068-2-6
Type Of Operator
spring return
Electrical Shock Protection Class
class II IEC 61140
Nema Degree Of Protection
NEMA 1 || NEMA 12 || NEMA 13 || NEMA 2 || NEMA 3 || NEMA 3R || NEMA 4
Light Block Supply
direct 24 to 28 V AC/DC
Device Short Name
9001K
Ambient Air Temperature For Operation
-25-70°C
Range of Product
Harmony 9001K

Description

PUSHBUTTON OPERATOR 30MM TYPE K +OPTIONS
