Shop SQUARE D

Manual Motor Starter, Not Applicable, 3 P, 3 Phase, Selector Switch, 1 A

  • Mfr # GV2P05

  • Zoro # G2611034

product price:  $285.99
/ea
Free Shipping & Returns

Key Features

Number of Poles
3
Operator
Selector Switch
Phase
3
Current AC
1 A
Series
TeSys Deca
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
GV2P05
Zoro #
G2611034
UPC #
785901832874
Country of Origin
Thailand

Dimensions

Overall Depth
3.82 in
Overall Width
1.77 in
Overall Height
3.5 in

Details

Item
Manual Motor Starter
Number of Poles
3
Operator
Selector Switch
Phase
3
Current AC
1 A
Series
TeSys Deca
Standards
ATEX Compliant, BV, CCC, CSA, DNV-GL, EAC, EN/IEC 60947-2, EN/IEC 60947-4, LROS, RINA, UKCA, UL Listed
Phase Loss Sensitivity
Yes
Description/Special Features
Screw Clamp Terminals, Single Unit
HP @ 3 Phase - 460-575V
1/2
HP @ 3 Phase - 575V
1/2 hp
Pilot Light
No
[Uimp] Rated Impulse Withstand Voltage
6 kV IEC 60947-2
Motor Power Kw
0.25-0.25 kW 400/415 V AC 50/60 Hz || 0.55-0.55 kW 690 V AC 50/60 Hz
Suitability For Isolation
yes IEC 60947-1§ 7-1-6
Phase Failure Sensitivity
yes IEC 60947-4-1
Tightening Torque
1.7 N.m screw clamp terminal
Product Name
TeSys GV2 || TeSys Deca
Rated Duty
continuous IEC 60947-4-1
Utilisation Category
category A IEC 60947-2 || AC-3 IEC 60947-4-1
Ik Degree Of Protection
IK04
Color
dark grey
Operating Altitude
6561.68 ft (2000 m)
Network Type
AC
Ambient Air Temperature For Storage
-40-80°C
Device Short Name
GV2P
Range
TeSys Deca
Thermal Protection Adjustment Range
0.63-1 A IEC 60947-4-1
Climatic Withstand
IACS E10
Fire Resistance
960°C IEC 60695-2-11
Trip Unit Technology
thermal-magnetic
Device Application
motor protection
Mechanical Robustness
shocks 30 Gn for 11 ms || vibrations 5 Gn, 5...150 Hz
Fixing Mode
35 mm symmetrical DIN rail clipped || panel screwed with 2 x M4 screws)
Power Dissipation Per Pole
2.5 W
Magnetic Tripping Current
13-13 A
Horsepower @ Three Phase - 600V AC
1/2 hp
Mechanical Operating Durability
100,000
Starter Style
IEC
Includes Pilot Light
No
NEMA Enclosure Rating
No Enclosure
Electrical Operating Durability
100,000
Status Indicator
No Indicator
Minimum Overload Relay Current Setting
0.63 A
IP Rating
IP20
Minimum Operating Temperature
-4 Degrees F
Resistance Properties
Fire Resistant
Terminal Connection Type
Screw Clamp Terminals
Maximum Operating Temperature
140 Degrees F
Maximum Voltage Rating
600V AC
Maximum Overload Relay Current Setting
1 A
Overload Protection Type
Thermal
Frequency
50/60 Hz
Horsepower @ Three Phase - 480V AC
1/2 hp
Rated Service Short-Circuit Breaking Capacity
100 % 230/240 V AC 50/60 Hz IEC 60947-2 || 100 % 400/415 V AC 50/60 Hz IEC 60947-2 || 100 % 440 V AC 50/60 Hz IEC 60947-2 || 100 % 500 V AC 50/60 Hz IEC 60947-2 || 100 % 690 V AC 50/60 Hz IEC 60947-2

Description

Manual Motor Starter, NEMA Size Not Applicable, Maximum Voltage Rating 600V AC, Number of Poles 3, Operator Selector Switch, Phase Three, Current AC 1 A, Horsepower @ Three Phase - 480V AC 1/2 hp, Series TeSys Deca, Horsepower @ Three Phase - 600V AC 1/2 hp, Maximum Overload Relay Current Setting 1 A, Minimum Overload Relay Current Setting 0.63 A, NEMA Enclosure Rating No Enclosure, Overload Protection Type Thermal, Starter Style IEC, Terminal Connection Type Screw Clamp Terminals
