Shop SQUARE D
See all product information
Miniature Circuit Breaker, E FRAME Series, 125A, 3 Pole, 277/480V AC, 25kA at 120V AC
Mfr # EDB34125SA
Zoro # G0845391
product price:Â $3,179.99
/ea
Free Shipping & Returns
Key Features
Series
E FRAME
Amps
125 A
Number of Poles
3
AC Voltage Rating
277/480V AC
Circuit Breaker Actuator
Toggle
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption
Specifications
Product Information
- MFR #
- EDB34125SA
- Zoro #
- G0845391
- UPC #
- 785901129820
- Country of Origin
- Mexico
Dimensions
- Frame Size
- 125A/EDB
- Width
- 3.92 in
- Depth
- 4.05 in
- Height
- 5.66 in
- Min. Wire Size
- 12 AWG (Al), 14 AWG (Cu)
- Max. Wire Size
- 2/0 AWG (Cu/Al)
Details
- Item
- Miniature Circuit Breaker
- Series
- E FRAME
- Amps
- 125 A
- Number of Poles
- 3
- AC Voltage Rating
- 277/480V AC
- Circuit Breaker Type
- Shunt Trip
- Circuit Breaker Actuator
- Toggle
- Circuit Breaker Mounting Style
- Bolt On
- Max. AIR Rating
- 25kA at 120V AC
- Trip Type
- Shunt Trip, Thermal Magnetic
- Terminal Connection
- Lugs
- DC Voltage Rating
- Not Rated
- For Use With
- NF Panelboard Accessory, NF Panelboards
- Interrupt Rating
- 18 kA at 277/480Y/277V AC, 25 kA at 120/240V AC
- High Amp Trip Setting
- 2300 A
- Application
- HACR rated Applications
- Standards
- cULus
- Features
- Mercury Free
Description
Miniature Circuit Breaker 480Y/277V 125A, Series EDB
