Shop SQUARE D

Miniature Circuit Breaker, E FRAME Series, 25A, 1 Pole, 600V AC, 25kA at 120V AC

  • Mfr # EDB16025

  • Zoro # G0845470

product price:
$
150.99
/ea
Free Shipping & Returns

Key Features

Series
E FRAME
Number of Poles
1
AC Voltage Rating
600V AC
Circuit Breaker Type
Standard
Circuit Breaker Actuator
Toggle
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
EDB16025
Zoro #
G0845470
UPC #
785901238454
Country of Origin
Mexico
Item
Miniature Circuit Breaker
Series
E FRAME
Amps
25 A
Number of Poles
1
AC Voltage Rating
600V AC
Circuit Breaker Type
Standard
Circuit Breaker Actuator
Toggle
Circuit Breaker Mounting Style
Bolt On
Max. AIR Rating
25kA at 120V AC
Trip Type
Thermal Magnetic
Terminal Connection
Lugs
DC Voltage Rating
Not Rated
Application
HACR rated Applications
Features
Mercury Free
Interrupt Rating
14 kA at 600Y/347V AC
High Amp Trip Setting
875 A
Standards
IEC, cULus
For Use With
NF Panelboard
Breaking Capacity Code
D
Protection Type
Short-circuit; Overload
Product Certifications
IEC; cULus
Breaking Capacity
14 kA 600Y/347 V AC
Tightening Torque
30.09 lbf.in (3.4 N.m) 0.00 to 0.02 in² (2.5 to 16 mm²) (AWG 14 to AWG 6)
Holding Current
270 A
Local Signalling
Trip indicator
AWG Gauge
AWG 12 to AWG 6 aluminium; AWG 14 to AWG 6 copper
Circuit Breaker Application
HACR rated
Module Type
E-Frame
Ambient Air Temperature For Operation
104°F (40°C)

Description

Miniature Circuit Breaker 600V 25A, Series EDB
