  9. Miniature Circuit Breaker, E FRAME Series, 30A, 1 Pole, 277V AC, 25kA at 120V AC
Square D Miniature Circuit Breaker, E FRAME Series, 30A, 1 Pole, 277V AC, 25kA at 120V AC EDB14030EPDBA - main

Miniature Circuit Breaker, E FRAME Series, 30A, 1 Pole, 277V AC, 25kA at 120V AC

  • Mfr # EDB14030EPDBA

  • Zoro # G0567799

product price: $1,352.99
/ea
Free Shipping & Returns

Key Features

Series
E FRAME
Amps
30A
Number of Poles
1
AC Voltage Rating
277V AC
Circuit Breaker Type
Ground Fault Circuit Interrupter
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
EDB14030EPDBA
Zoro #
G0567799
UPC #
785901786283
Country of Origin
Mexico

Dimensions

Frame Size
125A/EDB
Width
1.96 in
Depth
4.05 in
Height
6.64 in
Max. Wire Size
6 AWG (Cu), 4 AWG (Al)
Min. Wire Size
14 AWG (Cu), 12 AWG (Al)

Details

Item
Miniature Circuit Breaker
Series
E FRAME
Amps
30A
Number of Poles
1
AC Voltage Rating
277V AC
Circuit Breaker Type
Ground Fault Circuit Interrupter
Circuit Breaker Actuator
Toggle
Circuit Breaker Mounting Style
Bolt On
Max. AIR Rating
25kA at 120V AC
Trip Type
Thermal Magnetic
Terminal Connection
Lugs
DC Voltage Rating
Not Rated
Standards
cULus, IEC
Interrupt Rating
18 kA at 277/240/120V AC, 25 kA at 120V AC
For Use With
NF Panelboard
Features
Mercury Free
Application
HID rated Applications, HACR rated Applications
High Amp Trip Setting
875 A
Earth-Leakage Sensitivity
30 mA
Holding Current
270 A
Local Signalling
Trip indicator
Circuit Breaker Application
HID rated; HACR rated
Protection Type
Overload; Short-circuit
Ambient Air Temperature For Operation
104°F (40°C)
Breaking Capacity
18 kA 277 V AC; 18 kA 240 V AC; 25 kA 120 V AC; 18 kA 120/240 V AC
AWG Gauge
AWG 14 to AWG 6 copper; AWG 12 to AWG 4 aluminium
Breaking Capacity Code
D
Module Type
E-Frame
Product Certifications
cULus; IEC
Number Of Spaces
2
Tightening Torque
30.09 lbf.in (3.4 N.m) 0.00 to 0.02 in² (2.5 to 16 mm²) (AWG 14 to AWG 6)
Earth-Leakage Protection Class
Class B
Device Composition
Alarm switch

Description

Miniature Circuit Breaker 277V 30A, Series EDB
