Molded Case Circuit Breaker, 600V AC
Mfr # LAL361501021
Zoro # G222587713
product price:Â $5,824.99
/ea
Free Shipping & Returns
Key Features
Amps
150A
Number of Poles
3
AC Voltage Rating
600V AC
Circuit Breaker Type
Low Voltage
Circuit Breaker Actuator
Button
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption
Specifications
Product Information
MFR #
LAL361501021
Zoro #
G222587713
UPC #
-
Country of Origin
Mexico
Dimensions
Frame Size
150A/LA
Width
6 in
Depth
5.84 in
Height
11 in
Min. Wire Size
1 AWG
Details
Item
Molded Case Circuit Breaker
Amps
150A
Number of Poles
3
AC Voltage Rating
600V AC
Circuit Breaker Type
Low Voltage
Circuit Breaker Actuator
Button
Circuit Breaker Mounting Style
Unit Mount
Max. AIR Rating
22kA at 600V AC
Trip Type
Thermal Magnetic
Instantaneous Trip
Fixed
Terminal Connection
Line/Load Lug
Phase Connection
Non-Applicable
DC Voltage Rating
250V DC
High Amp Trip Setting
22 kA
For Use With
Control Equipment Panels
Min. Operating Temp.
14 Degrees F
Low Amp Trip Setting
10 kA
Standards
CSA Certified, IEC Certified, REACH Regulation, RoHS Directive, UL Listed
Max. Operating Temp.
104 Degrees F
Description
Molded Case Circuit Breaker, 150 A Amps, AC Voltage Rating 600V AC, Max. AIR Rating 22kA at 600V AC, For Use With Control Equipment Panels, High Amp Trip Setting 22 kA, Low Amp Trip Setting 10 kA, Circuit Breaker Type Standard, Number of Poles 3, DC Voltage Rating 250V DC, Terminal Connection Line/Load Lug, Trip Type Thermal Magnetic, Phase Not Applicable, Instantaneous Trip Fixed, Phase Connection Non-Applicable, Frame Size AL400LA, Circuit Breaker Mounting Style Unit Mount, Height 11 in
