Power Distribution Block, Open, 1 Pole, 175 A Copper, 600 V AC/DC, Surface Mount
Mfr # 9080LBA162101
Zoro # G3521244
CAD Available
product price:Â
$
13.29
/ea
Zoro's best price: not eligible for any other offers or promotions
Key Features
CAD Drawing
Power Distribution Block Design
Open
For Conductor Material
Aluminum, Copper
Maximum Current - Copper Conductor
175 A
Maximum Current - Aluminum Conductor
135 A
Maximum Voltage
600 V AC/DC
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 9080LBA162101
- Zoro #
- G3521244
- UPC #
- 785901097297
- Country of Origin
- Korea, Republic of
Dimensions
- Depth
- 1.78 in
- Width
- 1.13 in
- Length
- 2.88 in
- For Line Copper Wire Size - Maximum
- 2/0 AWG
- For Line Copper Wire Size - Minimum
- 14 AWG
- For Line Aluminum Wire Size - Maximum
- 2/0 AWG
- For Line Aluminum Wire Size - Minimum
- 14 AWG
- For Load Copper Wire Size - Minimum
- 14 AWG
- Overall Width
- 1.13 in
- For Load Aluminum Wire Size - Maximum
- 2/0 AWG
- For Load Aluminum Wire Size - Minimum
- 14 AWG
- For Load Copper Wire Size - Maximum
- 2/0 AWG
- Overall Length
- 2.88 in
- Overall Depth
- 1.78 in
- Wire Strip Length
- Line 0.5 in; Load 0.5 in
- Wire Rope Length
- 2.88 in
Description
Power Distribution Block, For Conductor Material Aluminum, Copper, Line Connections/Pole 1, Line Side Stud Size Not Applicable, For Line Copper Wire Size - Minimum 14 AWG, For Line Copper Wire Size - Maximum 2/0 AWG, Load Connections/Pole 1, Load Side Stud Size Not Applicable, For Load Copper Wire Size - Minimum 14 AWG, For Load Copper Wire Size - Maximum 2/0 AWG, Maximum Current - Copper Conductor 175 A, Maximum Voltage 600 V, Mounting Type Surface, Number of Poles 1, Overall Depth 1.78 in
