Relay, 240VAC Coil Volts, 4PDT
Mfr # 8501RS24V20
Zoro # G0571859
product price:Â
$
76.75
/ea
Key Features
Mounting Style
Socket
Coil Voltage
120V AC
Contact Form
4PDT
Body Height - Relay
27.9 mm
Contact Material
Gold Plated Bifurcated Silver
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 8501RS24V20
- Zoro #
- G0571859
- UPC #
- 785901031840
- Country of Origin
- China
Dimensions
- Body Height - Relay
- 27.9 mm
- Body Depth - Relay
- 41.5 mm
- Body Width - Relay
- 21 mm
Details
- Item
- Relay
- Mounting Style
- Socket
- Coil Voltage
- 120V AC
- Contact Form
- 4PDT
- Contact Material
- Gold Plated Bifurcated Silver
- Standards
- UL Listed; UL Recognized; CSA; CE
- Series
- Square D 8501R Miniature Series
- Operating Time
- 20 ms - pick-up || 20 ms - drop-out
- Pin Shape
- spade
- Operating Temp. Range
- -40-131°F
- Switching Voltage
- 300 V AC; 30 V DC
- Status Indicator
- No Indicator
- Electrical Connection
- Plug In
- Contact Rating (AC)
- 3 A @ 120/277V
- Current Rating
- 3 A
- Contact Rating (DC)
- 3 A @ 30V
- Number of Pins
- 14
Description
Relay, Status Indicator No Indicator
