Square D Relay, 240VAC Coil Volts, SPDT 8501RSD41V51 - main

Relay, 240VAC Coil Volts, SPDT

  • Mfr # 8501RSD41V51

  • Zoro # G0571831

product price:  $40.99
/ea

Key Features

Mounting Style
Socket
Electrical Connection
Pin
Coil Voltage
240V AC
Contact Form
SPDT
Contact Material
Silver Alloy, gold flashed
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
8501RSD41V51
Zoro #
G0571831
UPC #
785901137047
Country of Origin
China

Dimensions

Body Width - Relay
14 mm
Body Depth - Relay
41.8 mm
Body Height - Relay
27.3 mm

Details

Item
Plug-In Relay
Mounting Style
Socket
Electrical Connection
Pin
Coil Voltage
240V AC
Contact Form
SPDT
Contact Material
Silver Alloy, gold flashed
Standards
UL Listed; UL Recognized; CSA; CE
Series
Square D 8501R Miniature Series
Switching Voltage
300 V AC; 30 V DC
Operating Temp. Range
-40-131°F
Operating Time
20 ms - pick-up || 20 ms - drop-out
Pin Shape
spade
Status Indicator
No Indicator
Product Compatibility
8501NR41
Ambient Air Temperature For Operation
-40-131°F
Maximum Switching Voltage
300 V AC, 30 V DC
Rated Breaking Capacity
3 A 120 V AC inductive control circuit UL 508, 1.5 A 240 V AC inductive control circuit UL 508, 15 A 120 V AC resistive control circuit UL 508, 10 A 277 V AC resistive control circuit UL 508, 15 A 28 V DC resistive control circuit UL 508
Control Type
without test button
Rated Power In Hp
0.5 120 V AC, 1 277 V AC
Contact Rating (AC)
15 A @ 120/277V
Number of Pins
5
Contact Rating (DC)
15 A @ 28V
Current Rating
15 A

Description

Relay, Status Indicator No Indicator
