Magnet, Steel, 10ft. L, 10in D
- Mfr # R803-2042-D306
- Zoro # G9364415
product price:Â
$
19.69
/ea
Sold in multiples of 10 for
$196.90
Key Features
Material
Steel
Overall Length
1 ft
Tensile Strength
3,950 lbf
Roller Chain Type
Conveyor
Temp. Range
-15 Degrees to 300 Degrees F
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- R803-2042-D306
- Zoro #
- G9364415
- UPC #
- -
- Country of Origin
- Taiwan, Province of China
Dimensions
- Overall Length
- 1 ft
- Industry Chain Size
- C2042
- Pin Length
- 0.375
- Pin Link Plate Thickness
- 0.06 in
- Chain Roller Dia.
- 0.55 in
- Chain Overall Width
- 0.968 in
- Roller Bushing Width
- 0.312 in
- Overall Width
- 0.968"
- Chain Length
- 10 ft
- Inside Pin Dia.
- 0.156 in
- Roller Link Plate Height
- 0.463 in
- Length
- 1 ft
- Roller Dia.
- 0.55"
- ANSI Chain Size
- C2042
- Plate Thickness
- 0.06 in
- Inside Width
- 0.313 in
- Pin Hole Diameter
- 0.156 in
- Roller Diameter
- 35/64 in
- Plate Height
- 0.463 in
- Wire Rope Length
- 1 ft
- Fits Chest Size
- This Single-Strand Roller Chain is Designed to Help Transfer Motion From One Set of Sprockets to Another
Description
Chain, Chain Construction Riveted Pin, Overall Length 1 ft, Material Steel, Chain Number C2042, Chain Overall Width 0.968 in, Roller Diameter 35/64 in, Tensile Strength 3,950 lbf, Pitch 1 in, Application Attachment chain used in smaller scrap conveyors with Magnets or Drag flights on 6 In. or larger centers on 6 In. increments., Number of Strands 1, Pin Contruction Riveted Pin, Pitch Type Double Pitch, Inside Width 0.313 in, Series Conveyor, Working Load Limit 1,900 lb
