  9. SuperServer LGA1151 350W 1U RackmountServer BareboneSystem
This item is Discontinued.
Supermicro SuperServer LGA1151 350W 1U RackmountServer BareboneSystem SYS-5019S-MN4

SuperServer LGA1151 350W 1U RackmountServer BareboneSystem (Discontinued)

  • Mfr # SYS-5019S-MN4
  • Zoro # G6262987
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
SYS-5019S-MN4
Zoro #
G6262987
UPC #
672042203840
Country of Origin
Unknown

Dimensions

Height
1.7 in
Depth
19.8 in
Width
17.2 in
Rack Height
1U

Details

Voltage
120V AC, 230V AC
Features
64-bit Processing; Environmentally Friendly; RAID Supported
Includes
1 x Super X11SSH-LN4F Motherboard, 1 x 1U Chassis, 1 x SC811/SC512L/SC512F/SC813M/SC113M/SC513L-410B/SC513L-420B/SC513F, UP X9SRE/I, X9 Mylar Air Shroud, 12"x9.6" MB, 1 x 1U 4-Port 12Gbps Backplane Support 4x3.5\" SAS/SAS HDD/SSD, 1 x SET OF 4 SATA 56/45.5/35/23CM ROUND S-RA. 26AWG, 1 x 8 pin to 8 pin round SGPIO cable, 40cm, 28AWG, pinout 1-1,RoHS/REACH, 1 x Riser card bracket for SC812,813,813M,815,111,113,113M, 1 x Black 2x USB3.0/COM port tray in slim FDD bay, 1 x 5019S-MN4, QRG,HF,RoHS/REACH, 1 x RSC-RR1U-E16 with PCI-E x16 output, 1 x 1U PASSIVE CPU HS FOR INTEL LGA1156, 1 x 1U Single AC-DC 350W Platinum Level, multiple output power supply
Color
Black
Processor Socket
Socket H4 LGA-1151
Number of SATA Interfaces
4
Item
Server Barebone System
Memory Standard
DDR4-2133/PC4-17000
Number of PCI Express x8 Slots
1
Mounting
Rack
Memory Technology
DDR4 SDRAM
Ethernet Technology
Gigabit Ethernet
Number of Power Supplies Installed
1
Controller Type
Serial ATA/600
Number of 3.5" Bays
4
Maximum Memory Supported
64 GB
Number of USB Ports
4
Processor Supported
Core i3, Xeon
Number of USB 3.0 Ports
2
Number of Total Memory Slots
4
Power Supply
350 W
Number of Processors Supported
1
Number of Expansion Slots
2
Number of Total Expansion Bays
4
RAID Supported
Yes
Max. Memory Supported
64 GB
Chipset Model
C236
Max. Power Supply Wattage
350 W
Number of Memory Slots
4
Graphics Controller Manufacturer
ASPEED
Chipset Manufacturer
Intel
64-bit Processing
Yes
Green Environmental Attribute
Environmentally Friendly
Graphics Controller Model
AST2400

Description

SuperServer SYS-5019S-MN4 LGA1151 350W 1U Rackmount Server Barebone System (Black)
