  9. SY-F618R3T SuperServer Four Node Dual LGA2011 1280W 4U

This item is Discontinued.

Supermicro SY-F618R3T SuperServer Four Node Dual LGA2011 1280W 4U SYS-F628R3-FT

SY-F618R3T SuperServer Four Node Dual LGA2011 1280W 4U (Discontinued)

  • Mfr # SYS-F628R3-FT
  • Zoro # G6252803
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
SYS-F628R3-FT
Zoro #
G6252803
UPC #
672042167517
Country of Origin
Unknown

Dimensions

Depth
29 in
Height
7 in
Width
17.6 in
Rack Height
4U

Details

Voltage
120V AC, 230V AC
Features
64-bit Processing; Environmentally Friendly; Network (RJ-45); QuickPath Interconnect Supported; RAID Supported; VGA
Color
Black
Standards
ACPI 1.0, ACPI 2.0
Includes
(4) Super X10DRFF Motherboard, (1) 4U Chassis, (4) 4x 3.5, (4) 2x2 to 2x2 15cm power cable HF. 18AWG, (4) 8 pin to 8 pin ribbon SGPIO cable with tube, 27cm, PBF, 1(6) 21cm 30AWG SATA S-S cable, (4) RSC-R1UFF-E16R, (8) 2U Passive CPU Heat Sink for X9, X10 Generation Systems Equipped w/ a Square ILM MB, (4) 1U 1280W, redundant single output power supply
RAID Levels
0, 1
Maximum Memory Supported
512 GB
Number of SATA Interfaces
4
Mounting
Rack
Processor Supported
Xeon
Number of Total Expansion Bays
4
Number of Nodes
4
Number of Power Supplies Installed
4
Item
Server Barebone System
Number of PCI Express x16 Slots
1
Memory Standard
DDR4-2133/PC4-17000
Number of USB Ports
2
Number of Expansion Slots
1
Number of Processors Supported
2
Power Supply
1280 W
Processor Socket
Socket LGA 2011-v3
QuickPath Interconnect
9.60 GT/s
Number of USB 3.0 Ports
2
Controller Type
Serial ATA/600
Memory Technology
DDR4 SDRAM
Ethernet Technology
Gigabit Ethernet, Fast Ethernet
Number of Total Memory Slots
8
Number of 3.5" Bays
4
Chipset Manufacturer
Intel
RAID Supported
Yes
Graphics Controller Model
AST2400
64-bit Processing
Yes
Network (RJ-45)
Yes
Green Environmental Attribute
Environmentally Friendly
Max. Power Supply Wattage
1280 W
Graphics Controller Manufacturer
ASPEED
VGA
Yes
Max. Memory Supported
512 GB
Number of Memory Slots
8
QuickPath Interconnect Supported
Yes
Chipset Model
C612 Express

Description

SuperServer SYS-F628R3-FT Four Node Dual LGA2011 1280W 4U Rackmount Server Barebone System (Black)
