Product Information
MFR #
1-796641-2
Zoro #
G500983299
UPC #
-
Country of Origin
Italy
Dimensions
Screw Size
M3
Details
Mounting Angle
Right Angle
Housing Material
Polyamide 6.6 GF
Wire Range
.05 to 3 mm² [ 30 to 12 AWG ]
Shrouded
No
Number of Rows
1
Block Type
None
Interlock
Without
Housing Color
Black
Contact Mating Area Plating Material
Tin
Wire Entry Angle
Side
Screw Flange
Without
Screwless Terminal Block
No
Connector Style
Plug
Contact Base Material
Phosphor Bronze
Side Stackable
Yes
Screw Material
Brass
Centerline
5 mm [ .197 in ]
Applies To
Wire/Cable
Current Rating (Max) (A)
15
Voltage (VAC)
300
Number of Positions
12
Screw Plating Material
Nickel
