  11. 1.25 WTB HDR DIP 3 POS
This item is Discontinued.
Te Connectivity 1.25 WTB HDR DIP 3 POS 1734598-3

1.25 WTB HDR DIP 3 POS (Discontinued)

  • Mfr # 1734598-3
  • Zoro # G000937686
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
1734598-3
Zoro #
G000937686
UPC #
-
Country of Origin
China

Dimensions

Width
0.126 in
Height
0.185 in
Length
5.5 mm
Contact Plating Thickness
3.048 µm

Details

Item
Connector
Color
Natural
Insulation Material
High Temperature Thermoplastic
Max. Voltage
100V AC
Maximum Voltage
100 V AC
Current
0.8 A
Maximum Operating Temperature
85 Degrees C
UL 94 Flammability Rating
V-0
Wire Type
Discrete
Material
High Temperature Thermoplastic
Connection Material
Phosphor Bronze
Connector Type
Header
Features
Partially Shrouded
Wire Range
28 AWG
Terminal Type
Through Hole
Hole Center to Center
1.25 mm
For Use With
440146-x
Max. Temp.
85°C
Contact Finish
Nickel Plated; Tin over Nickel
Contact Type
Pin
Number of Contacts
3
Current Rating
0.8 A
Number of Rows
1
Terminal Finish
Tin Plated
Flammability Rating
UL 94 V-0
