Contact our U.S. based teamSpecifications
Product Information
MFR #
1-1609112-5
Zoro #
G200983476
UPC #
-
Country of Origin
China
Dimensions
Panel Thickness Range
.8 to 2.5 mm [ .031 to .098 in ]
Details
Voltage Selection
None
Low Profile
Yes
Input Type
IEC, Pre-Connected
Leakage Current (Max) (250VAC, 50Hz) (µA)
5
Filtered
No
Fuse Options
None
Mount Style
Snap-In
Filter Type
Power Entry Module
Current Rating (A)
15
Switch Type
SPST
Output Type
.187" FASTON, Socket to Switch
Voltage (Max) (VAC)
250
Mount Angle
Vertical
Leakage Current (Max) (120VAC, 60Hz) (µA)
2
Shield Style
None
Type of Connector
IEC 60320-1 C-14
Operating Temperature Range (°C)
-10 to 40
