Shop TE CONNECTIVITY

16P VRT HDR VAL-U-LOK V2 W/ODH

  • Mfr # 1-2029172-6

  • Zoro # G800937299

product price:
$
0.93
/ea
Sold in multiples of 83 for $77.19

Key Features

Type
Header
Insulation Material
Nylon
Max. Voltage
600V AC
Maximum Voltage
600 V AC
Application
Power
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
1-2029172-6
Zoro #
G800937299
UPC #
-
Country of Origin
United States

Dimensions

Width
0.383 in
Height
12.8 mm
Length
34.8 mm

Details

Item
Connector
Type
Header
Insulation Material
Nylon
Max. Voltage
600V AC
Maximum Voltage
600 V AC
Application
Power
Current
9 A
Standards
CSA Certified; UL E28476; UL Recognized
Maximum Operating Temperature
105 Degrees C
UL 94 Flammability Rating
V-2
Terminal Type
Through Hole - Solder
Max. Temp.
105°C
Features
Shrouded
Hole Center to Center
4.19 mm
Material
Nylon
Connector Type
Header
Contact Type
Pin
Number of Rows
2
Contact Finish
Tin Plated
Number of Contacts
16
Current Rating
9 A
Flammability Rating
UL 94 V-2
Connector Terminates To
Printed Circuit Board
Termination Style
Through Hole - Solder

Documents & Resources
