Product Information
MFR #
173722-1
Zoro #
G501009318
UPC #
-
Country of Origin
China
Dimensions
Wire Size
26 - 20 AWG
Overall Length
.677 in
Mating Tab Width
.187 in
Mating Tab Thickness
.019 in
Accepts Wire Insulation Diameter Range
.051 - .141 in
Wire Insulation Diameter (Max)
.141 in
Receptacle Stock Thickness
.011 in
Details
Terminal Type
Receptacle
Disconnect Type
Quick Disconnect
Barrel Type
Open
Discrete Wire Type
Stranded
Plating Material
Pre-Tin
Wire Insulation Support
With
Fully Insulated
No
Voltage (Max)
250 V
Operating Temperature Range
-40 105 °C
Crimp Type
F-Crimp
Terminates To
Wire & Cable
Wire/Cable Type
Discrete Wire
Contact Base Material
Brass
Terminal & Splice Style
Receptacle
Terminal Orientation
Straight
