Product Information
MFR #
207305-1
Zoro #
G101043156
UPC #
-
Country of Origin
United States
Dimensions
Width
27.84 mm
Length
41.4 mm
Details
Item
Connector
Wire Connector Style
Square Grid
Max. Voltage
600V AC/DC
Max. Temp.
130°C
Standards
CSA Certified; UL E28476; UL Certified and Recognized
Features
Panel Mount Feature
Material
Nylon
For Use With
Socket Header; Plug Housing
Color
Red
Connector Type
Receptacle
Hole Center to Center
5 mm
Number of Contacts
24
Wire Type
Discrete; Stranded
Flammability Rating
UL 94 V-0
Connector Terminates To
Printed Circuit Board; Wire & Cable
Number of Rows
6
Contact Type
Pin
