Contact our U.S. based teamSpecifications
Product Information
MFR #
3-1825138-6
Zoro #
G001009726
UPC #
-
Country of Origin
China
Dimensions
Toggle Length
10.4 mm [ .41 in ]
Bushing Thread Size
14614
Bushing Length (in)
0.37
Details
Switch Type
Toggle
Process Sealed
No
Sealed
Yes
Mounting Type
Through Hole
Toggle Style
Baton Long
Actuator Finish
Nickel
Toggle Actuation
Vertical
Contact Base Material
Copper
Operating Function
On (On)
Seal Type
Terminal Seal (Epoxy)
Dielectric Strength (VAC)
1000
Bushing Style
Threaded
Configuration (Pole-Throw)
Double Pole - Double Throw
Insulation Resistance (MΩ)
1000
Termination Type
Printed Circuit
Contact Resistance (mΩ)
10
Voltage Rating
20 V
Product Type
Switch
Contact Plating
Gold
