Contact our U.S. based teamSpecifications
Product Information
MFR #
4-1825059-9
Zoro #
G600966604
UPC #
-
Country of Origin
Malaysia
Dimensions
Length
1.078 in
Height
.138 in
Contact Mating Area Plating Thickness
1.2µin
Details
Housing Color
Black
Housing Material
Polyphenylene Sulfide (PPS)
Operating Temperature Range
-30 to 85°C
Voltage Rating
5 VDC
Sealed
No
Number of Switches
10
Solder Tail Contact Plating
Nickel
Configuration (Pole-Throw)
Single Pole - Single Throw
Auto-Insertable
Yes
Termination Style
Outside L
Actuator Style
Slide, Flush
Switch Type
DIP
Actuator Color
White
Contact Current Rating
1A
Centerline
.1 in
Contact Base Material
Copper Alloy
Contact Mating Area Plating Material
Gold Flash
Number of Positions
10
UL Flammability Rating
UL 94V-0
Mounting Type
Surface Mount
Product Type
Switch
