Contact our U.S. based teamSpecifications
Product Information
MFR #
6367550-7
Zoro #
G301044816
UPC #
-
Country of Origin
China
Dimensions
Contact Plating Thickness
0.76 µm
Details
Item
Connector
Max. Temp.
85°C
Application
Signal
Features
With Center Ground Plate
Material
Polyester
Color
Natural
Connector Terminates To
Printed Circuit Board
Connector Type
Plug
Contact Type
Pin
Flammability Rating
UL 94 V-0
Number of Contacts
192
Terminal Finish
Tin Plated
Current Rating
7 A; 0.5 A
Hole Center to Center
2.54 mm
Connection Material
Copper Alloy, Phosphor Bronze
Number of Rows
6
Contact Finish
Gold Plated; Gold over Nickel
