Product Information
MFR #
61518-1
Zoro #
G700984553
UPC #
-
Country of Origin
United States
Dimensions
Contact Diameter
.084 in
Details
For Use With
Pin (Cap) Housing
Contact Classification
Power
Connector Mounting Type
Board Mount
Operating Temperature Range
-55 to 105 °C
Termination Method to Printed Circuit Board
Solder Tab
Contact Termination Area Plating Material
Tin
Contact Current Rating (Max)
15 A
Operating Voltage
250 VAC
Contact Base Material
Phosphor Bronze
Contact Retention Type
Locking Lance
Connector & Contact Terminates To
Wire & Cable
Connector System
Wire-to-Board
Product Type
Contact
Contact Type
Pin
Termination Method to Wire & Cable
Crimp
Wire/Cable Type
Stranded, Discrete Wire
Contact Mating Area Plating Material
Pre-Tin
Circuit Application
Power
Contact Retention
With
