Contact our U.S. based teamSpecifications
Product Information
MFR #
178325-5
Zoro #
G505910016
UPC #
-
Country of Origin
China
Dimensions
Height
21.6 mm
Width
0.568 in
Length
1.15 in
Details
Color
Black
Item
Connector
Number of Rows
2
Series
3000
Max. Voltage
250V AC/DC
Standards
CSA Certified; UL E28476; UL Recognized
Connector Type
Header
Material
Glass-Filled Polyester
Terminal Type
Through Hole - Solder
Max. Temp.
105°C
For Use With
Receptacle Housing
Green Environmental Attribute
Halogen Free
Features
Shrouded
Hole Center to Center
0.149 in
Contact Finish
Tin Plated
Connector Terminates To
Printed Circuit Board
Number of Contacts
10
Current Rating
15 A
Terminal Finish
Tin Plated
Flammability Rating
UL 94 V-0
Contact Type
Tab
