Contact our U.S. based teamSpecifications
Product Information
MFR #
5-6437630-7
Zoro #
G500967060
UPC #
-
Country of Origin
Japan
Dimensions
Toggle Length
10.5 mm [ .413 in ]
Bushing Thread Size
M6 x .75
Bushing Diameter
Threaded
Details
Color
Black
Switch Type
Toggle
Seal Type
Waterproof
Sealed
Yes
Bushing Style
Threaded
Termination Type
Lead Wire - Hooking Type, Vertical
Toggle Style
Baton Standard
Dielectric Strength (VAC)
1500
Operating Function
(On) None On
Contact Base Material
Copper Alloy
Contact Resistance (mΩ)
10
Configuration (Pole-Throw)
Single Pole - Double Throw
UL Flammability Rating
UL 94V-0
Contact Current Rating (A)
6
Insulation Resistance (MΩ)
1000
Mounting Type
Solder
Product Type
Switch
Toggle Actuation
Vertical
Process Sealed
No
Contact Plating
Silver
