Contact our U.S. based teamSpecifications
Product Information
MFR #
1469002-1
Zoro #
G700937498
UPC #
-
Country of Origin
China
Dimensions
Length
24.9 mm
Contact Plating Thickness
0.76 µm
Details
Color
Gray
Insulation Material
Glass-Filled Polyester
Current
0.7 A
Maximum Operating Temperature
105 Degrees C
UL 94 Flammability Rating
V-0
Connector Type
Header
Connection Material
Phosphor Bronze
Max. Temp.
105°C
Hole Center to Center
2.5 mm
Terminal Type
Press-Fit
Material
Glass-Filled Polyester
Application
Signal
Contact Finish
Gold Plated
Contact Type
Pin
Number of Rows
8
Number of Contacts
80
Current Rating
0.7 A
Flammability Rating
UL 94 V-0
Connector Terminates To
Printed Circuit Board
Terminal Finish
Tin-Lead over Nickel
