Product Information
MFR #
2057748-3
Zoro #
G801064314
UPC #
-
Country of Origin
China
Dimensions
Width
1/2 in
Height
11.95 mm
Length
30.3 mm
Contact Plating Thickness
0.76 µm
Hole Dia.
0.015 in
Details
Item
Connector
Max. Voltage
30V AC/DC
Max. Temp.
85°C
Application
Signal
Standards
CSA Certified; UL E28476; UL Recognized
Material
Liquid Crystal Polymer
Color
Black
Current Rating
0.75 A
Terminal Type
Through Hole - Press-Fit
Number of Contacts
96
Connector Type
Receptacle
Contact Type
Pin
Hole Center to Center
1.9 mm
Number of Rows
6
Terminal Finish
Matte Tin Plated
Connection Material
Copper Alloy
Flammability Rating
UL 94 V-0
Connector Terminates To
Printed Circuit Board
Contact Finish
Gold Plated
