Contact our U.S. based teamSpecifications
Product Information
MFR #
2007738-1
Zoro #
G101069095
UPC #
-
Country of Origin
China
Dimensions
Width
1.469 in
Height
27.1 mm
Length
0.748 in
Contact Plating Thickness
0.76 µm
Hole Dia.
0.018 in
Details
Item
Connector
Max. Voltage
30V AC/DC
Max. Temp.
85°C
Application
Signal
Standards
CSA Certified; UL E28476; UL Recognized
Color
Black
Material
Glass-Filled Liquid Crystal Polymer
Number of Contacts
180
Contact Finish
Gold Plated
Current Rating
0.75 A
Flammability Rating
UL 94 V-0
Terminal Type
Through Hole - Press-Fit
Connector Terminates To
Printed Circuit Board
Connection Material
Copper Alloy
Number of Rows
18
Terminal Finish
Matte Tin Plated
Contact Type
Socket
Connector Type
Receptacle
Hole Center to Center
1.9 mm
