Contact our U.S. based teamSpecifications
Product Information
MFR #
6450130-3
Zoro #
G500940261
UPC #
-
Country of Origin
China
Dimensions
Contact Plating Thickness
0.076 µm
Details
Item
Header
Color
Black
Insulation Material
High Temperature Thermoplastic
Max. Voltage
300V AC/DC
Maximum Voltage
300 V AC/DC
Application
Power, Signal
Current
42 A
Maximum Operating Temperature
105 Degrees C
UL 94 Flammability Rating
V-0
Material
High Temperature Thermoplastic
Connection Material
Tin
Hole Center to Center
7.62 mm; 2.54 mm; 6.35 mm
Max. Temp.
105°C
Terminal Type
Through Hole - Solder
Contact Type
Pin
Number of Contacts
32
Number of Rows
4
Contact Finish
Noble Metal Plated
Current Rating
42 A
Connector Terminates To
Printed Circuit Board
Terminal Finish
Tin Plated
Flammability Rating
UL 94 V-0
