Product Information
MFR #
207018-1
Zoro #
G801052663
UPC #
-
Country of Origin
United States
Details
Item
Connector
Wire Connector Style
Square Grid
Color
Red
Insulation Material
Nylon
Max. Voltage
600V AC/DC
Maximum Voltage
600 V AC/DC
Standards
CSA Certified; UL E28476; UL Certified and Recognized
Maximum Operating Temperature
130 Degrees C
UL 94 Flammability Rating
V-0
Max. Temp.
130°C
Material
Nylon
Features
Panel Mount Feature
Connector Type
Receptacle
Wire Type
Discrete; Stranded
Hole Center to Center
5 mm
For Use With
Socket Header; Plug Housing
Number of Contacts
12
Number of Rows
4
Contact Type
Pin
Flammability Rating
UL 94 V-0
