Product Information
MFR #
4-1658012-2
Zoro #
G001068594
UPC #
-
Country of Origin
China
Dimensions
Height
3.05 mm
Contact Plating Thickness
0.25 µm
Details
Item
PCB Mount Receptacle
Max. Temp.
125°C
Max. Voltage
125V AC
Application
Signal
Series
Mictor SB
Features
With Boss
Material
Liquid Crystal Polymer
Terminal Type
Surface Mount
Terminal Finish
Gold Plated
Hole Center to Center
0.8 mm
Current Rating
1.25 A; 9.5 A
Contact Finish
Select Gold Plated
Connector Terminates To
Printed Circuit Board
Connection Material
Phosphor Bronze
Number of Rows
2
Number of Contacts
80
Contact Type
Socket
