PE0SXS000=C4898
- Mfr # 8-6609955-4
- Zoro # G500985149
product price:Â
$
28.69
/ea
Sold in multiples of 4 for
$114.76
Key Features
For Use With
P Series
Voltage Selection
2-Voltage
Leakage Current (Max) (120VAC, 60Hz) (µA)
2
Mount Style
Flanged
Leakage Current (Max) (250VAC, 50Hz) (µA)
5
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 8-6609955-4
- Zoro #
- G500985149
- UPC #
- -
- Country of Origin
- Mexico
Dimensions
- Panel Thickness Range
- .7874 to 2 mm [ .031 to .079 in ]
Details
- For Use With
- P Series
- Voltage Selection
- 2-Voltage
- Leakage Current (Max) (120VAC, 60Hz) (µA)
- 2
- Mount Style
- Flanged
- Leakage Current (Max) (250VAC, 50Hz) (µA)
- 5
- Voltage (Max) (VAC)
- 115, 230
- Level Of Filtering
- Inductor & Capacitor
- Switch Type
- DPST
- Filtered
- No
- Current Rating (A)
- 10
- Type of Connector
- IEC 60320-1 C-14
- Fuse Options
- Single
- Input Voltage Select
- Dual AC (Series/Parallel)
- Mount Angle
- Vertical
- Operating Temperature Range (°C)
- -10 to 40
- Filter Type
- Power Entry (Filtered/Unfiltered)
- Output Type
- .187" FASTON
- Shield Style
- None
- Input Type
- IEC
- Accessory Type
- Fuse Clip
