  13. Piano Dip Switch, 1 Switches, Spst, Latched, 0.025A, 24Vdc, 4 Pcb Hole Cnt, Solder Terminal,

This item is Discontinued.

Te Connectivity Piano Dip Switch, 1 Switches, Spst, Latched, 0.025A, 24Vdc, 4 Pcb Hole Cnt, Solder Terminal, 1571998-1

Piano Dip Switch, 1 Switches, Spst, Latched, 0.025A, 24Vdc, 4 Pcb Hole Cnt, Solder Terminal, (Discontinued)

  • Mfr # 1571998-1
  • Zoro # G605812883
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
1571998-1
Zoro #
G605812883
UPC #
-
Country of Origin
China

Dimensions

Height
7.7 mm [ .3 in ]
Length
6.05 mm [ .238 in ]
Termination Post Length
3.56 mm [ .14 in ]
Contact Mating Area Plating Thickness (µin)
10

Details

Product Type
Switch
Number of Switches
2
Contact Current Rating (A)
0.1
Sealed
Yes
Housing Color
Black
Actuator Color
White
Solder Tail Contact Plating
Gold over Nickel
Contact Mating Area Plating Material
Gold
UL Flammability Rating
UL 94V-0
Centerline
2.54 mm [ .1 in ]
Auto-Insertable
No
Actuator Style
Piano (Side Actuated)
Switch Type
DIP
Operating Temperature Range (°C)
-30 to 85
Voltage Rating (VDC)
50
Contact Base Material
Copper Alloy
Mounting Type
Through Hole
Number of Positions
2
Configuration (Pole-Throw)
Single Pole - Single Throw
Seal Type
Tape
Mounting Angle
Vertical
Housing Material
Polyphenylene Sulfide (PPS)

Description

Piano Dip Switch, 1 Switches, Spst, Latched, 0.025A, 24Vdc, 4 Pcb Hole Cnt, Solder Terminal, Through Hole-Straight
