Contact our U.S. based teamSpecifications
Product Information
MFR #
170332-1
Zoro #
G201026332
UPC #
-
Country of Origin
Japan
Dimensions
Wire Size
18 - 14 AWG
Overall Length
.85 in
Accepts Wire Insulation Diameter Range
.082 - .141 in
Receptacle Stock Thickness
.012 in
Mating Tab Thickness
.02 in
Mating Tab Width
.187 in
Wire Insulation Diameter (Max)
.141 in
Details
Terminal Type
Receptacle
Insertion Force
Normal
UL Rating
Recognized
Terminal & Splice Style
Receptacle
Fully Insulated
No
Discrete Wire Type
Stranded
Barrel Type
Open
Terminates To
Wire & Cable
Wire Insulation Support
With
Wire/Cable Type
Discrete Wire
Contact Base Material
Brass
Operating Temperature Range
-40 105 °C
Crimp Type
F-Crimp
Plating Material
Pre-Tin
Disconnect Type
Quick Connect
Terminal Orientation
Straight
Mating Retention Type
Dimple
