Contact our U.S. based teamSpecifications
Product Information
MFR #
170331-1
Zoro #
G901009147
UPC #
-
Country of Origin
Japan
Dimensions
Wire Size
20 - 16 AWG
Overall Length
.85 in
Mating Tab Thickness
.02 in
Mating Tab Width
.187 in
Accepts Wire Insulation Diameter Range
.075 - .134 in
Receptacle Stock Thickness
.012 in
Wire Insulation Diameter (Max)
.134 in
Details
Terminal Type
Receptacle
Discrete Wire Type
Stranded
Mating Retention Type
Dimple
Operating Temperature Range
-40 105 °C
Crimp Type
F-Crimp
Wire/Cable Type
Discrete Wire
Barrel Type
Open
Terminal Orientation
Straight
Insertion Force
Low
Terminates To
Wire & Cable
Contact Base Material
Brass
Fully Insulated
No
UL Rating
Recognized
Wire Insulation Support
With
Terminal & Splice Style
Receptacle
Plating Material
Pre-Tin
Description
