Product Information
MFR #
172457-2
Zoro #
G200937219
UPC #
-
Country of Origin
United States
Dimensions
Height
20.5 mm
Length
4.799 in
Contact Plating Thickness
0.76 µm
Details
Item
Header
Color
Black
Max. Voltage
350V AC
Maximum Voltage
350 V AC
Maximum Operating Temperature
105 Degrees C
UL 94 Flammability Rating
V-0
Max. Temp.
105°C
Hole Center to Center
5.08 mm
Material
Glass-Filled PBT
For Use With
Receptacle Assembly
Current Rating
6 A
Contact Finish
Gold Plated
Number of Contacts
40
Number of Rows
2
Contact Type
Pin
Connector Terminates To
Printed Circuit Board
Terminal Finish
Tin Plated; Gold Plated
Flammability Rating
UL 94 V-0
