Contact our U.S. based teamSpecifications
Product Information
MFR #
4-6609950-9
Zoro #
G100985501
UPC #
-
Country of Origin
Mexico
Dimensions
Panel Thickness Range
.7874 to 2 mm [ .031 to .079 in ]
Details
For Use With
P Series
Shield Style
None
Output Type
.187" FASTON
Voltage (Max) (VAC)
115, 230
Current Rating (A)
10
Input Type
IEC
Mount Angle
Vertical
Extender Options
L Series
Operating Temperature Range (°C)
-10 to 40
Switch Type
None
Mount Style
Snap-In
Filter Type
Power Entry (Filtered/Unfiltered)
Level Of Filtering
Inductor & Capacitor
Input Voltage Select
Dual AC (Series/Parallel)
Voltage Selection
2-Voltage
Type of Connector
IEC 60320-1 C-14
Leakage Current (Max) (250VAC, 50Hz) (µA)
5
Fuse Options
Single
Leakage Current (Max) (120VAC, 60Hz) (µA)
2
Filtered
Yes
Accessory Type
Fuse Clip
