Product Information
MFR #
6-1415074-1
Zoro #
G401026576
UPC #
-
Country of Origin
Mexico
Details
Item
Power Relay
Mounting Style
DIN Rail
Electrical Connection
Screw Terminals
Coil Voltage
230V AC
Contact Form
2 Form C (CO)
Number of Poles
2
Power Consumption - Relay
1VA
Item - Relay
Relay Package PT
Contact Material
AgNi90/10
Features
Manual Operation; Electrical Indicator, LED
Contact Limiting Breaking Current
12A
Coil Type
Monostable, AC
Protection Category
RTI
Insulation Clearance
4 mm [ .157 in ]
Contact Voltage Rating
240V AC
Contact Limiting Making Current
24A
Switching Voltage
400V AC
Contact Limiting Short-Time Current
12A
Dielectric Voltage
2500 Vrms Adjacent Contacts; 1200 Vrms Coil and Contact; 2500 Vrms Open Contacts
Coil Resistance
19465 Ω
Insulation Creepage
4 mm [ .157 in ]
Contact Limiting Continuous Current
12A
Contact Rating
12A
Operating Temp. Range
50 to 70°C
