Product Information
MFR #
696018-2
Zoro #
G500976321
UPC #
-
Country of Origin
United States
Dimensions
Wire Size
22 - 18 AWG
Overall Length
.8 in
Wire Insulation Diameter (Max)
.135 in
Receptacle Stock Thickness
.016 in
Mating Tab Width
.205 in
Mating Tab Thickness
.02 in
Details
Voltage (Max)
300 V
Insertion Force
Low
Barrel Color
Red
Crimp Type
F-Crimp
Fully Insulated
No
Disconnect Type
Quick Disconnect Pin
FASTON
Yes
Plating Material
Tin
Terminal Orientation
Straight
Terminates To
Wire & Cable
Operating Temperature Range
105 °C
Insulated
Yes
Discrete Wire Type
Stranded
Wire Insulation Support
With
Mating Retention Type
Dimple
