SHORT POINT RECP CONT LP
Mfr # 1-104480-6
Zoro # G500973580
product price:Â
$
0.23
/ea
Sold in multiples of 428 for $98.44
Key Features
Wire Contact Termination Area Plating Material
Tin
Contact Base Material
Copper Alloy C7025
Contact Type
Socket
Contact Transmits (Typical)
Signal (Data)/Power
Product Type
Contact
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 1-104480-6
- Zoro #
- G500973580
- UPC #
- -
- Country of Origin
- China
Dimensions
- Contact Mating Area Plating Thickness
- 30 µin
- Insulation Diameter
- .025 to .06 in
- Crimp Area Plating Thickness
- 50 µin
- Wire/Cable Size
- 26 to 22 AWG
Details
- Wire Contact Termination Area Plating Material
- Tin
- Contact Base Material
- Copper Alloy C7025
- Contact Type
- Socket
- Contact Transmits (Typical)
- Signal (Data)/Power
- Product Type
- Contact
- Connector & Contact Terminates To
- Wire & Cable
- Contact Style
- Crimp Snap-In
- Wire/Cable Type
- Discrete Wire
- Dielectric Withstanding Voltage
- 750 V
- Wire Insulation Support
- With
- Termination Method to Wire & Cable
- Crimp
- Applied Pressure
- Standard
- Insulation Resistance
- 5000 MΩ
- Operating Voltage
- 300 VAC
- Termination Resistance
- 12 mΩ
- Approved Standards
- UL E28476, CSA LR7189
- Operating Temperature Range
- -65 to 105 °C
- Contact Current Rating (Max)
- 3A
- Contact Mating Area Plating Material
- Gold
- Contact Termination Area Plating Material
- Gold
