Side Mounting Plate, Socket, Power Relay, 2 Pins, Plug-in, Solder
Mfr # 1-1393768-0
Zoro # G605865827
product price:Â
$
63.55
/ea
Sold in multiples of 2 for $127.10
Key Features
Mounting Style
Side Mounting Plate, Socket
Electrical Connection
Plug In, Solder
Number of Pins
2
Coil Voltage
24V DC
Contact Material
Ag
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 1-1393768-0
- Zoro #
- G605865827
- UPC #
- -
- Country of Origin
- Mexico
Details
- Item
- Power Relay
- Mounting Style
- Side Mounting Plate, Socket
- Electrical Connection
- Plug In, Solder
- Number of Pins
- 2
- Coil Voltage
- 24V DC
- Contact Material
- Ag
- Features
- Sensitive Version; Bifurcated/Twin Contacts
- Power Consumption - Relay
- 900 mW
- Number of Poles
- 2
- Contact Voltage Rating
- 120 VAC
- Coil Resistance
- 700 Ω
- Switching Current
- 1mA @ 12V
- Contact Rating
- 8.33333333333333E-02A
- Protection Category
- RTI
- Contact Limiting Continuous Current
- 2A
- Coil Type
- Monostable, DC
- Contact Limiting Making Current
- 2A
- Operating Temp. Range
- -55 to 75°C
- Contact Limiting Breaking Current
- 2A
- Dielectric Voltage
- 1000 Vrms Adjacent Contacts; 1000 Vrms, 1000 V Coil and Contact; 500 Vrms Open Contacts
- Contact Limiting Short-Time Current
- 2A
- Base Shape
- Square
- Current Rating
- 2 A
Documents & Resources
