Contact our U.S. based teamSpecifications
Product Information
MFR #
1612534-1
Zoro #
G501052420
UPC #
-
Country of Origin
China
Dimensions
Length
5.7 mm
Height
1.4 mm
Wire/Cable Size
32 AWG
Height above PC Board
.057 in
Details
Housing Color
Black
Contact Current Rating (Max)
.5 A
Strain Relief
Without
Connector Assembly Type
PCB Mount Receptacle
Contact Mating Area Plating Material
Gold
Contact Base Material
Phosphor Bronze
Centerline (Pitch)
.8 mm
Mating Retention
Without
Housing Material
Thermoplastic
Number of Positions
2
Connector Type
Connector Assembly
Mating Alignment
Without
Product Type
Connector
Pick and Place Cover
Without
PCB Mount Alignment
Without
Contact Retention
Without
Backwall/Post Interruptions
Without
Number of Rows
2
PCB Mounting Style
Surface Mount
